It takes some experimentation but generally circles 3 foot in diameter need about 500 segments. To make a smoother cutting arc, select entity info and increase the number of segments until each segment length is about. Arcs as simply drawn in Sketchup’s abbreviated polygon fashion will leave a large segmented appearance and will cut on the machine that way.
The resulting high number of segments in the shape of a circle (100 for about 3” diameter, 600 for about 30” diameter) will cut smoothly with little distortion. You can increase the circles’ segments until the individual segment length is low (0.06), then explode. If you plan on exploding the circle into individual segments, scalling or distorting the circle you will need to increase its segment count to represent the curve in the g-code with adequate resolution. you can change the resolution of the circle by simply clicking ENTITY INFO. This value will be remembered and come up as a changeable default every time you draw a circle.
If you plan on keeping the circle intact (not scaling, or making it intersect a line) this can be ignored. Right after you select to draw a circle, the number of segments desired will be in the lower left of the screen. The circle can intersect other geometry making it a curve of constant radius (see arcs below). dxf export as true equations of a circle and so will cut as an equation in the G-code.
#SKETCHUP IMAGE TO DXF CONVERTER PRO#
A circle exported with Sketchup Pro as a. This advice is for the native shape generation: Advanced circle tools are available from other plugins.
Once a component it can be copied and any changes to any of the copies or the original updates across similar components. Just like any other group, a circle turned into a group can be turned then into a component. A circle drawn in Sketchup Pro will export as a true equation of a circle so long as it is not stretched into an oval or exploded or drawn in such a way that one of its edges touches a geometry. Remember that if you hover over an edge of the circle, the auto snap will activate the center of the circle. Draw the desired radius circle off part somewhere, layer name it, Drill z0p486 (example), group it, then move it into position on the desired surface. To organize complex cut paths you can lift them up into the z axis, it is ignored on dxf export so long as the top view is active when you do the 3d export to dxf. Keep the group names all on Layer 0, to avoid the situation of import problems. In sketchup a line carries both its layer name and the layer name of the group of entities it has been grouped together with. Lines can be placed on top of one another in the z axis, but two different lines apart of two different groups traveling along the same location of xyz to xyz cannot. SketchUp Pro->.dxf -> Thermwod CNC For most 2d drawn tool paths. IGES FILESĬLOSING NOTES AND SAMPLE PROCESSING TIMES ĬUTTING TECHNIQUES FOR COMPLEX OR SMALL PARTS ON A VACUUM TABLEĪDOBE ILLUSTRATOR TO SKETCHUP TO CNC VIA. SKETCHUP TO THERMWOOD CNC (or other dxf to g-code converting program). End of this document has typical pencil drawing to parts start cut times for different types of panel board boxes.
#SKETCHUP IMAGE TO DXF CONVERTER CODE#
dxf directly to the machine control cabinet where g code is generated with auto written tool changes, nesting, flip operations, sheet changes, drill operations, pocket operations, pop up pins and other measures that allows start button operation once the g-code compiles. With those CNC machines, you can export a. It was written based on experience with a 3 axis Thermwood CNC router.
#SKETCHUP IMAGE TO DXF CONVERTER SOFTWARE#
The process guide outlined here combines the fast drawing capabilities of Sketchup with the fast working g-code generation software for Thermwood CNC or similar dxf to g code creation software. sketchup warehouse ball end miter cut paths link. Sketchup plugins suited for CNC drawing quality work. Here is a guide for using SketchUp with to create dxf files suitable for CNC machine cut path generation.
